Solar Powered Outdoor System Wireless Security CCTV Solar Camera With 5G Sim Card

Solar Cell

156Mono

Optimum Power

18V

Optimum operating current

3.33A

5.55A

Short Circuit voltage

3.66

6.11

Open Circuit Voltage

21.24v

Size Module

680*510*30mm

870*670*30mm

Front Gass Thickness

3.2mm

Tolerance Watts

±3%

Surfacer Max Load Capacity

60m/s (5kgf sq.m)

Allowable Hail Load

23m/s,7.53g

Temperature range

-20°C to +85°C

Weight Per Piece(KG)

4KG with Battery

Cell Efficiency

21.6%

Warranty

90% for 10 years, 80% for 25 years

Water proof

IP67

Size of Battery

205x100x40mm

205x112x68mm

Module

60W

100W

Battery

Lithium Ion-222WH

Lithium Ion-444WH

Load Voltage

9 ~ 12.6V

Max Charge

10A

Solar Input Voltage

18V

Max Load

40W

Array Mode

3S10P

3S20P

Nominal Capacity

20000mAh

40000mAh

Minimum Capacity

>20000mAh

>40000mAh

Nominal Voltage

11.1V

Opertating Temp

0°C〜65°C (Charging) / -20°C〜65°C Discharging Operating

Cycle Life

>500*
